CyBio Well vario 96, 384 and 1536 channel simultaneous pipettor
- Extremely flexible through enormous volume spectrum
- Highest precision in the whole volume range
- Unique pipetting technology prevents cross contamination
Product Details
Multiple Heads on a Solid Base
The CyBio Well vario includes an automated base which accepts different interchangeable simultaneous pipetting heads. The heads can be changed quickly and easily either at the front or the back of the instrument. After head exchanges the calibration maintains. A working volume range of four orders of magnitude allows liquid transfers from 25 nl up to 250 µl on one platform, either with 96 or 384 disposable tips. The CyBio Well vario adapts into any screening environment and it is compatible with all other accessories of the CyBio Well family.
The innovative CyBio Composer Software. supports the flexibility of the system and immediately detects the new head.
- Extremely flexible through enormous volume spectrum
- Highest precision in the whole volume range
- Unique pipetting technology prevents cross contamination
- Easy application set-up using CyBio Composer software
- Saves reagent costs with accurate low volume pipetting
Pipetting heads
| Head 96/25 µl |
|
|---|---|
| Head 96/60 µl |
|
| Head 96/250 µl |
|
| Head 384/25 µl |
|
| Head 384/60 µl |
|
| Head 1536/8 µl |
|
| Capillary Head |
|
CyBio Well vario 1536 Head
The pipetting head uses CyBio's unique and well-proven tip sealing system. The 1536 air displacement pistons allow the simultaneous transfer and filling of all wells of a 1536-well plate in one single step.
Specifications
| Volume range: | Precision [CV in %]* of specified volume range: | |
|---|---|---|
| Head 96/25 µl | 0.5-25 µl | 0.5 ≤ 10% 2-5 µl ≤ 2% >5-25µl ≤ 1% |
| Head 96/60 µl | 1–60 µl | 3-5 µl ≤ 2% >5-60 µl ≤ 1% |
| Head 96/250 µl | 5-250 µl | 25-100 µl ≤ 2% 25-250 µl ≤ 1% |
| Head 384/25 µl | 0.5-25 µl | 2-5 µl ≤ 2% >5-25 µl ≤ 1 |
| Head 384/60 µl | 1–60 µl | 3-5 µl ≤ 2% >5-60 µl ≤ 1% |
| Head 1536/8 µl | 1–8 µl | 1-5 µl ≤ 3% 5-8 µl ≤ 2% |
| Capillary Head | 0.050-1 µl | 0.025-1,0 µl ≤ 10% |
*The specification of precision and trueness is based on the Analytik Jena internal gravimetric and photometric standard measurement procedure, which is published as Annex B7 in the ISO IWA 15 document "Specification and method for the determination of volumetric performance of automated liquid handling systems" (www.IWA15.org). The Application Note "Photometric and Gravimetric Liquid Handling Check Procedure to determine the Random Error (Precision) and the Systematic Error (Accuracy) of Automated Liquid Handling Systems (ALHS)" describes this measuremet procedure in detail.
Every modification of this method may influence the results
Technical Data
Footprint (W x D in mm)
| 3-place linear transporting unit | 960 x 370 mm |
| 4-place linear transporting unit | 1300 x 370 mm |
| 5-place linear transporting unit | 1650 x 370 mm |
| 10-place circular transporting unit | 700 x 895 mm |
Height (mm)
772.5 mm
Pipette Channel
96, 384, 1536
Pipetting Tips
Disposable tips/capillaries
Plate Formats
96, 384, 1536
Plate Capacity
- 3 with 3-place linear transporting unit
- 4 with 4-place linear transporting unit
- 5 with 5-place linear transporting unit
- 10 with 10-place circular transporting unit
Volume Range
| Wet pipetting: | 50 nl bis 250 μl |
| Dry pipetting: | 200 nl bis 250 μl |
Weight
| 39,5 kg | 3,4 and 5 place linear transporting unit |
| 49 kg | 10-place circular transporting unit |
Software
CyBio Composer Software
The CyBio Well vario is controlled by the CyBio Composer Software:
- Powerful scripting environment
- Direct access to all hardware functions and liquid handling parameters
- Possibility of connecting to databases and LIMS systems
Applications
A three, four, five or ten - position carriage handles high-precision pipetting needs with high flexibility and ample deck space to run the application successfully. The high flexibility of the CyBio Composer Software supports any application.
- Reformatting
- Replication
- Plate coating
- Biochemical assays
- ADME and cytotoxicity assays
- Compound management Molecular Biology assays (RNA silencing)
- Cell handling
- uHTS MALDI Sample Preparation — Beyond Spotting
| Applications | |
|---|---|
| Application Reports | Technical Reports |
"How to Use" Guide for the Capillary Head of the CyBio Well vario | |
Start-up Routine and Tip Washing Efficiency Data of the Active Deep Well Tip Wash Station 384 | |
| Precision of the new Ceramic Type Capillary Magazines 384 of the CyBio Well vario Capillary Head — Example Data
| |
Optimized Washing of Disposable Tips after Transfer of DNA Samples | |
Results of Pipetting of Small Volumes using a 384 CyBio Well | |
Performance and reliability testing of a new capillary based non-contact liquid handling system | |
Precise low volume compound handling with the new Nanoliter Head of CyBio Well vario | |
| Precision of the CyBio Well vario 384/60 µL Head, Example Data of Different Liquids, Pipetting Modes and Disposable Tips with Fluorescence Readout |
| Stability of the Precision of Different CyBio-Well vario Heads after Multiple Tip Washing Routines |
| |
| Performance Data demonstrating the Efficiency of the Tip Wash Station of the CyBio Well Family |
Accessories
Plate Transfer Unit
This additional module can be mounted to the CyBio Well or CyBio Well vario and allows the automatic relocation of a microplate to any carriage position.
Microplate Adapter
Micro plate adapter allow you to use any type of micro plates of various manufacturers on our devices incl. adapter for specific application requirements.
Automated Reservoir Filling
The reagent reservoirs are designed for the storage and automatically refilling of liquids, such as buffers or DMSPO and more.
Barcode Handling
For creation of barcodes, labeling of microplates as well as reading of barcodes within the process we offer tailor-made solutions.
Tip Wash Station
With the aid of these wash modules, tips in the 96 and 384 format can be washed automatically with pump-supported (active) inflow and drain, which helps you to reduce disposable costs.
Plate Handling and Storage
Efficient microplate storage with stackers enables fully automated processing of large batches of plates and increases your walk-away time.
Tip Changer
For high throughput applications, where tip changing is necessary, the TipChanger can store up to 100 tip racks.
